Mini Roll Transfer Machine
Mini Roll Transfer Machine
Product ID: WE-TCB-1
  • Roller Core Dimension : φ20 x φ60 x 100 (mm)
  • Stroke : 350 (mm)
  • Work Table : 280 x 380 (mm)
  • Max. Opening : 300 (mm)
  • Reach : 210 (mm)
  • Heater Capacity : 400 x 6
  • Dimension (L x W x H) : 1,340 x 700 x 1,800 (mm)
  • Packaging WT. : 320 kg
  • Packaging Dimension : 850 x 1,400 x 1,900 (mm)
  • Net WT : 250 kg
  • To control sequence with three timers: Press, Deley, Foil Feed. The adjustment is easily as one's pleases and accuracy.
  • Operating temperature can be adjusted from 0 ~ 400°C easily and accurately.
  • Double foil feed roll guide.
  • High efficiency structure of pneumatic system and an auto lubricator is employed with easily adjustment and high stability and durability.
  • Beam sensor is easy to adjust and accuracy.
  • The level of herater is easily and fast adjusted.
  • Accuracy depth adjustment can be achieved with micro-adjustment.
  • FC25 structure is steel casting never deformed and good lasting.
  • Foil feeder with special motor rotates very accurately.
  • Aluminum alloy plate is light and strong.
  • Both hands push button prevent industrial accident.
  • The machine can be easily moved by the working table with wheels.
  • Foot switch with safety cover.
